iFi Audio Zen Phono V3

Features

• MM/MC with 36-72dB gain range
• Independent loading adjustment
• Super-silent -151dBV noise floor
• Precise RIAA with balanced output
• Intelligent subsonic filter
• High-tech 1.2MHz clean power supply

Specifications

• Gain Settings
  • MM 36dB
  • MC High 48dB
  • MC Low 60dB
  • MC V-Low 72dB
• Max Output Voltage (RMS)
  • Bal 100kΩ: ≥19.98V (THD+N <1%)
  • 600Ω: ≥12.75V (THD+N <1%)
  • SE 100kΩ: ≥10.07V (THD+N <1%)
  • 600Ω: 7.94V (THD+N <1%)
• Output Impedance
  • BAL200Ω
  • SE 100Ω
• Input Impedance
  • MM: 47KΩ (100/200pF)
  • MC High: 47kΩ (100/200pF)
  • MC Low: 1k/400/100Ω
  • MC V-Low: 1k/400/100Ω
• SNR
  • MM91dB(A)/82dB (unweighted 80kHz BW) (2V Balanced, 1V Single-Ended)
  • MC High 81dB(A)/72dB (unweighted 80kHz BW)
  • MC Low    89.6dB(A)/80dB (unweighted 80kHz BW)
  • MC V-Low78.6dB(A)/69dB (unweighted 80kHz BW)
• Harmonic Distortion
  • MM <-91dB/0.0027% (2V Balanced, 1V Single-Ended @ 600Ω)
  • MC High <-80dB/0.0095%
  • MC Low <-70dB/0.031%
  • MC V-Low <-73dB/0.022%
• Channel Separation >75dB (1kHz all modes)
• Frequency Response
  • BAL 20Hz-80kHz (-3dB)
  • SE 20Hz-20kHz (-0.15dB)
• Dimensions (Length x Width x Height) 158 x 115 x 35mm
• Net Weight 456g
• Power Supply Requirement DC 5V/0.5A (centre positive)
