ELAC Cinema 30 Home Theater System

The Cinema 30
Based on the successful BS 302, the Cinema 30 Set offers a full complement of loudspeakers, but with dimensions that make it hard to believe its true capabilities. The high-gloss paintwork also makes them an elegant addition to any interior. Supported by the powerful SUB 2030, this surround-sound system creates a huge soundstage where even the finest details of movies and music are revealed and the lowest frequencies are felt as well as heard.

Product Specifications

• SUB2030 Specifications:
•

• Speaker Type:
• Powered subwoofer, closed box

• Woofer:
• 1 x 250 mm cone

• Frequency Response:
• 20 to 180 Hz

• Crossover Frequency:
• 44 – 160 Hz, selectable

• Amplifier Type:
• BASH-Tracking

• Maximum amplifier power:
• 350 Watts Max

• Standby power consumption:
• 1 Watt

• Maximum power consumption:
• 480 Watts (full load)

• Inputs:
•  2x line-channel (RCA)

• Input sensitivity:
•  2 x 70 mV (RCA)

• Input Impedance:
•  10 kΩ (RCA)

• Cabinet finish:
• Matte black or white

• Accessories included:
• AC Power Cable

• Dimensions (WxHxD):
• 11.8in / 300mm, 14.0in / 356mm, 12.4in / 315mm

• Weight:
• 30.1 lb / 14.0 kg

• BS302:
•

• Speaker Type:
• 2-way, closed box, high-pass integrated/li>

• Tweeter:
• 1 x 20 mm cloth dome

• Woofer:
•  1 x 78 x 108 mm AS oval cone

• Crossover Frequency:
• 80/2,390 Hzz

• Frequency Response:
• 80 to 35,000 Hz

• Sensitivity:
• 86 dB at 2.83 v/1m

• Recommended amplifier power:
• 20 to 120 wpc

• Nominal/peak power handling:
• 60 / 75 wpc

• Nominal impedance:
•  4 Ω; minimum 3.5 Ω @ 1,200 Hz

• Binding posts:
• 5-way metal

• Magnetic shielding:
• Yes

• Cabinet finish:
• High gloss black, gray or white

• Accessories included:
• Metal grille

• Dimensions (WxHxD):
• 3.6 in / 91mm, 4.8 in / 121mm, 4.4 in / 111 mm

• Net weight (each):
• 2.9lb / 1.3kg
