JBL Stage 260F Home Theater System 5.1 + Ραδιοενισχυτές AV JBL MA510.

JBL Stage 260F Home Theater System 5.1  + Ραδιοενισχυτές AV JBL MA510.

Includes:

 Specifications of JBL Stage 240B Bookshelf Speaker

• Tech Specs

  - Type: Bookshelf Loudspeaker System
  - Low Frequency Driver: 4.5-inch (114mm) Polycellulose Ribbed Cone
  - High Frequency Driver: 1-inch (25mm) Anodized Aluminum
  - Waveguide: Next Generation HDI™
  - Recommended Amplifier Power: 20-125W
  - Frequency Response ± 6dB: 53Hz-25kHz
  - Sensitivity @ 1M, 2.83V: 85dB
  - Nominal Impedance: 6 Ohms
  - Crossover Frequencies: 1.4Khz
  - Enclosure Tuning: Bass Reflex via Rear-Firing Tuned Port
  - Finish: Espresso or Latte
  - Dimensions (HxWxD):  (272mmx175mmx217mm)
  - Product Weight:   (4.6 kg)
  - Shipping Weight:  (10.4kg)

 Specifications of JBL Stage 260F Floorstanding Speaker



• Tech Specs

  - Type: Floorstanding Loudspeaker System
  - Low Frequency Driver: Dual 6.5-inch (165mm) Polycellulose Ribbed Cone
  - High Frequency Driver: 1-inch (25mm) Anodized Aluminum
  - Waveguide: Next Generation HDI™
  - Recommended Amplifier Power: 20-225W
  - Frequency Response ±6dB: 40Hz-25kHz
  - Sensitivity @ 1M, 2.83V: 90dB
  - Nominal Impedance: 6 Ohms
  - Crossover Frequencies: 1.3kHz/1.7kHz
  - Enclosure Tuning: Bass Reflex via Dual Flared Racetrack Rear-Firing Tuned Ports
  - Finish: Espresso or Latte
  - Dimensions (HxWxD):  (1036mm x 310mm x 362mm)
  - Dimensions (HxWxD) without Base:  (1036mm x 200mm x 354mm)
  - Product Weight:   (19.5kg)
  - Shipping Weight:  (24.1kg)

 Specifications of the JBL Stage 245C Center Channel



      Tech Specs

          - Type: Center Channel Loudspeaker System
          - Low Frequency Driver:Quad 4.5-inch(114mm)Polycellulose Ribbed                  Cone.
          - High Frequency Driver: 1-inch (25mm) Anodized Aluminum
          - Waveguide: Next Generation HDI™
          - Recommended Amplifier Power: 20-150W
          - Frequency Response ≡ 6dB: 55Hz-25kHz
          - Sensitivity @ 1M, 2.83V: 91dB
          - Nominal Impedance: 6 Ohms
          - Crossover Frequencies: 1.3kHz/2.0kHz
          - Enclosure Tuning: Bass Reflex via Dual Rear-Firing Tuned Ports
          - Finish: Espresso or Latte
          - Dimensions (HxWxD):  (156mm x 740mm x 217mm)
          - Product Weight:   (12.0kg)
          - Shipping Weight:  (14.7kg)



 Specifications of the JBL Stage 200P Subwoofer



     Tech Specs

• Type: Active subwoofer
• Woofer: 10-inch high excursion polycellulose rib
• Amplifier power: 150W RMS (300W Dynamic)
• Frequency response ± 6dB: 28Hz-150Hz
• Crossover frequencies: 50Hz-150Hz (variable) 24dB/octave
• Controller: 35Hz-150Hz
• Controls: Auto Power, Transition, Level, Phase
• Inputs: One (1) line-level LFE input
• Cabinet tuning: Bass reflex via two rear tuned ports
• Power supply: 120V, 60Hz (US) 220-230V, 50/60Hz (EU)
• Power consumption: <0.5W (standby) / 205W/1.6A (max – 230V) / 205W/3.15A (max – 120V)
• Surface: Espresso or Latte
• Dimensions (HxWxD):  (361mm x 350mm x 385mm)
• Product weight:   (14.4 kg)
• Shipping weight:  (18.3 kg)



 Specifications of the JBL MA510 Ολοκληρωμένος Πολυκάναλος   Ενισχυτής 5.2 κανάλιών



     Tech Specs

General Specifications

HDMI eARC Yes

HDMI Audio Return Channel Yes

8K HDMI input connectors (HDMI 2.1, HDCP 2.3 up to 8K/60Hz, 4K/120Hz) 4

HDMI 2.1 enhanced gaming features Gaming-VRR, ALLM, QFT, HFR (4K@120Hz)

HDR 10+, Dolby Vision Yes , Yes

File format MP3 / MPEG-4 AAC

Pure Direct Yes

EZ Set EQ Yes

Digital signal processing up to 24-bit/192kHz

Mains voltage 110 – 240V, 50–60Hz

Max. power consumption 300W

Standby power consumption <0.5W

Audio Specifications

Channels 5.2

Rated Power @ 8Ω (20Hz – 20kHz, 2 channels driven, 0.5% THD max) 75 W RMS

Rated Power @ 4Ω (20Hz – 20kHz, 2 channels driven, 0.5% THD max) 100 W RMS

Dimensions

Dimensions incl. feet and speaker terminals (H x W x D)  (109.2mm x 432.0mm x 347.6mm)

Weight  (5.4kg)

Control and Connection Specifications

HDMI Input/Output 4 / 1

Wi-Fi Yes (2.4/5GHz)

Bluetooth receiver Yes (v4.1, Low Energy)

Digital Audio Input 1 Coax, 1 Optical, 1 USB

Stereo analog input 2 single-ended RCA

Pre-Out (single ended RCA) Subwoofer 1, Subwoofer 2

Ethernet RJ45 Gigabit, WiFi Onboard.

• Dimensions (W x D x H) 335 x 380 x 340mm
• Weight 30.05 lbs (13.63kg)

Κατασκευαστές	JBL
