Bryston BHA-1 Balanced Headphone Amplifier

Item Description

Advancing our tradition of unmatched audio performance and functionality, the BHA-1 Balanced Headphone Amplifier is our solution to delivering the finest listening experience from your headphones.

Functionally a miniature power amplifier, we applied the same robust design elements to the BHA-1 amplifier that we used to develop our full size amps. Six class A fully discrete operational amplifiers

generate your headphone output, delivering up to 2 watts of power for more than adequate dynamic range. The BHA-1 provides a true balanced mode via balanced outputs, or you can use the single-ended

outputs for more traditional headphones. The BHA-1 also has a pair of XLR outputs which allow you to use the unit as a high quality analog preamplifier. Hear the best your headphones have to offer by powering

them with a BHA-1.

Features

• 3 stereo inputs: RCA, XLR, and 3.5mm TRS
• Fully Class A discrete operational amplifiers.
• Low distortion, high power output
• Balanced output
• Switchable gain
• Fully convection cooled means no noisy fans
• Machined and anodized aluminum enclosure and dress panel
• Legendary Bryston 20 Year Warranty

Specifications

Dimensions: Inches: 17 or 19 W x 2.71 H x 11.10 D
Weight: 11.7 lbs | 5.3 kg
Frequency Response: 20Hz – 20kHz
THD+N (20Hz-20kHz @ Rated Power): <0.005%
Power Output (per channel): 2W @ 32Ω
Input Impedance: Unbalanced 10KΩ / Balanced +15kΩ/-5kΩ
Sensitivity: HI (approx 20 dB) setting: 70mV in = 100 mW out into 50 Ω (500mV in = 5V out) / LO (approx 14 dB) setting: 140mV in = 100 mW out into 50 Ω (500mV in = 2.5V out)
