Zidoo Z3000 PRO

Zidoo Z3000 Pro

Overview

Extraordinary 8K UHD

The Zidoo Z3000 PRO is a premium media player designed to deliver an exceptional home entertainment experience. With support for 8K UHD resolution, Dolby Vision, and HDR10+, this device ensures stunning picture quality and vibrant colours.

The Z3000 PRO is perfect for movie enthusiasts and audiophiles, offering extensive support for the latest audio and video formats.

High-Performance 8k Media Chipset

Amlogic S928X-K 64bit 8K high-performance multi-function chipset. Big performance jump from the previous generation.

Dual HDMI Ports

HDMI 2.1 port for 8K video. HDMI 1.4a port for audio. The second HDMI port allows an upgrade to 8K/4K video whilst retaining HDMI 1.4 AVR for audio.

Internal 3.5" HDD Bay

Front access plug and play NSS patented internal 3.5" SATA 3.0 hard drive bay. Hidden access, integrated into the front panel. Max 16TB.

8GB RAM & 64GB Storage

8GB high specification DDR4 RAM. 64GB onboard eMMC storage.64-bit memory bandwidth.

Zidoo Hardware Quality

Aluminium alloy brushed panel, large LED display panel, high-quality internal switching and linear power supply.

Zidoo Home Theatre 5.0

Zidoo have developed the Zidoo Home Theatre media browser over almost a decade. On the new Amlogic chipset it runs significantly faster than before, supporting near limitless library size. Zidoo Home Theatre supports full and accurate automatic

media scraping (multi-language), thumbnails, posters, synopsis, search, categories and support for NFO (Kodi) parsing. Integration with the new Zidoo Android/iOS control app. Support for SMBv1, SMBv2, SMBv3, NFS, and DLNA network protocols.

Updated interface. Zidoo Home Theatre is the ultimate way to browse a digital video media collection.

Zidoo Music Player 8.0

Enhanced Zidoo Music Player 8.0 taken from the successful audiophile Eversolo streamers. New user interface. Comprehensive music library with enhanced scraping, auto lyric find and artist/album info.

Integration with the new Zidoo Android/iOS control app. Audio format support including native DSD passthrough, DSD512, PCM 768KHz@32bit, CD output at 44.1Khz, SACD, DFF, DSF, FLAC, CUE lists, MP3, OGG.

Audio Streaming

Integrated support for streaming apps such as Tidal Connect, Qobuz, Deezer, and Squeeze Lite*.

Zidoo Video Player

Modern and easy-to-use Zidoo Video Player with a powerful subtitle function. Format support including Dolby Vision, HDR10+, HDR10, AV1, HEVC, H.265, MVC 3D @23.976Hz, HDR>SDR and SDR>HDR, ATMOS, DTS:X. Easy access to image settings.

Enhanced Subtitles

Multi-language subtitle function with customisable fonts, subtitle download, forced subtitles, graphics special effect subtitles and Blu-Ray/ MKV dual forced subtitles.

Zidoo Firmware Development & User Engagement

Zidoo has manufactured specialist media playback Android boxes for a decade and has proven its commitment to continuous product development. Zidoo's playback interface and media browser represent the culmination of many years of work.

They are stable, fully featured, and represent the best possible way to enjoy your media. Zidoo has a popular web forum where users are welcome to post feedback, resulting in a firmware developed reactively according to user needs.

Auto Refresh & Resolution Switching

Fully configurable fast automatic resolution switch (e.g. 1080p video at 1080p HDMI output, 4K video at 4K HDMI output) and fast refresh rate change (output Hz = input fps, e.g. 23.976fps @ 23.976Hz).

ISO Playback

Improved ISO playback compared to the previous generation. Playback of DVD/BD/UHD-BD including full support for auto resolution/refresh and seamless branching. Blu-Ray/Blu-Ray/DVD ISO full menu on approximately 90% of ISOs, the rest play with custom Zidoo menu.

Fast Networking

2.4G + 5G dual-band MIMO Wi-Fi 6 with internal antenna. Gigabit Ethernet. Bluetooth 5.2.

Bluetooth Remote & New Remote App

Full-sized backlit remote with Bluetooth for non-line-of-sight operation. Learning function to replicate existing remotes. New and much improved Zidoo Android/iOS remote app with full Zidoo Home Theatre and Zidoo Music Player control. Developed from the highly respected Eversolo audio control app.

Smart Home

Supports HDMI CEC control, RS232 control, Control 4, TCP/IP(WOL).

Box Contents

Zidoo Z3000 Pro, Zidoo V12 backlit full-sized Bluetooth and IR remote, IEC C13 power lead, HDMI cable and user guide. Package weight: 5kg.

*Support for third-party apps can and will change over time.



Other Features

• New generation Amlogic S928X-K 64-bit penta-core A76 + A55 high-performance multi-functional processor.

• 8GB DDR4 RAM + 64GB eMMC storage, providing smooth operation, meets the needs for installing numerous applications.

• Dual HDMI audio and video separate output can enjoy 4K video and HD audio at the same time without upgrading the AV receiver.

• Smooth Android 11 OS significantly improved system performance and stability.

• Aluminum alloy brushed panel, large LED display panel, high-quality switch power supply.

• Hidden NSS patented HDD bay supports capacity up to 16TB; Built-in Wi-Fi and BT Antenna.

• HDMI 2.1® supports 8K 60Hz point-to-point output, supports HDR (HDR10/HLG/HDR10+/Dolby Vision).

• Supports AV1/VP9/H.265/AVS3/AVS2 video codecs, 12-bit, BT.2020 wide color range; supports Atmos/DTS X audio pass-through output.

• Built-in VS10 image quality engine is highly customizable, significantly improving image quality by custom mapping different video modes.

• Processing HDR10 static metadata (MaxFall, MaxCll) more accurately which shows higher brightness and deeper darkness level.

• Supports acquiring and processing HDR10+ dynamic metadata, colours and brightness are processed frame by frame and scene by scene.

• Automatic frame rate of 23.976 and resolution switching output ensures smooth movie playback without interruption (supports local playback and online streaming).

• Supports BD/UHD Blu-ray menu playback and gapless branching playback of Blu-rays with complex MPLS structure.

• Supports lossless music playback in formats like DSD (SACD ISO, DSF, DFF), WAV, APE, and DTS.

• Supports special effect subtitles and automatic download of network subtitles; Zidoo is the only one in the field to support Blu-ray and MKV dual forced subtitles.

• Supports multiple music streaming methods, such as DLNA, Tidal Connect, etc.

• New Poster Wall 4.0 supports movie trailers and user-friendly custom classification and management.

• Upgraded music player 8.0 with brand new UI main interface, supports lossless playback and decoding, personalized settings, and song data matching.

• Supports HDMI® CEC control, RS232 control, Control 4, and seamless integration into a smart home.

• Supports the exclusive Zidoo Controller APP for iOS and Android mobile phones, iPad landscape mode and Android tablet landscape mode, which can seamlessly play and control Zidoo media players.

• Supports access to network protocols like NFS, SMB v1/v2/v3, UPnP, Web DAV, and built-in SMB service.



Specifiche

Model	Z3000 PRO
Front Display	LED
Chassis	Aluminium alloy
OS	Android 11
CPU	Amlogic S928X-K ARM Cortex-A76+Cortex-A55 (Penta-core)
GPU	ARM Mali-G57 MC2
RAM	8GB DDR4
Internal Storage	64GB eMMC
Bluetooth	BT 5.2
WiFi 6	2.4G+5G dual band WiFi, 802.11 a/b/g/n/ac/ax 2T2R , 802.11ax MIMO OFDM
Ethernet	1*RJ-45(10/100/1000Mbps)
HDMI Out (Main)	HDMl 2.1a, supports up to 8K@60p, HDR10+,12Bit color depth, BT2020 wide color range; Supports HDR10, HDR10+,HLG, Dolby Vision; Supports Dolby Atmos and DTS X audio pass-through
HDMI Out (Audio Only)	HDMI separate audio and video output supports Dolby Atmos and DTS X audio pass-through, as well as multi-channel PCM and DSD output
Video Decoding Audio Decoding	8K@60p AV1/VP9/H.265/AVS3/AVS2; HDR10, HDR10+, HLG, Dolby Vision Supports Dolby/DTS format (up to Dolby TrueHD Atmos and DTS X) decoding
Audio Output Intelligent Control	USB output, Optical output*1, Coaxial output*1, RCA L/R channel output*1 APP control for iPhone,iPad landscape mode, Android phone, Android tablet landscape mode, RS-232, TCP/IP control (supports WOL)
Power Supply	AC 110~120/220~240V 50/60Hz
USB	2*USB3.0, 1*USB2.0
SATA	One built-in 3.5''HDD bay with SATA 3.0 specification (HDD is not included)
Other Interface	1*IR Receiver, 1*RCA Cvbs, 1*RCA L/R Channels, 1*Coaxial Output (2CH,5.1CH) , 1*SPDIF Output (2CH,5.1CH), 1*RS232, 1*IR IN 3.5’’ Headphone Jack
Accessories	1*Remote Control, 1*Power Adapter, 1*SATA Cable, 1*HDMI Cable, 1*User Manual
Dimensions	350mm x 241 mm x 60mm
Product weight (excluding accessories)	2.9 Kg
